33KV Lightning Arrester

The arrester is a kind of arrester zinc oxide. After the distribution type of zinc oxide is modified, it is skillfully installed on the drop mechanism of the droplet fuse, so that the power supply will not be cut off.The insulation brake lever can be used to test, repair and replace the arrester easily, which not only ensures the unblocked circuit, but also greatly reduces the working intensity and time of maintenance personnel.Especially suitable for traffic, airport, station, hospital, busy business district and other unsuitable places.

Characteristics:

1. The arrester unit is rechargeable

2. Using isolation switch, the arrester unit can automatically drop, quit operation, timely maintenance and replacement in case of failure.

3. As a result of the failure, the unit was turned over with a clear indication that it was easy to find in order to facilitate timely maintenance and replacement.

4. Composite sheath for lightning arrester, composite pillar for anti-fall mechanism, with good hydrophobicity and strong antifouling ability.

Conditions:

1. Ambient temperature: -40℃~+40℃;

2. Altitude not greater than 3000m;

3. Power frequency: 48Hz~62Hz;

4. Maximum wind speed shall not exceed 35m/S:

5. Areas with earthquake intensity of 7 and below.

Product Specifications：

Main Technical Parameter：

Our Advantage:

1. We have been engaged in fuse for more than 15 years.

2. We have experienced engineers and professional QC to ensure your product better.

3. Our company with strong strength, reasonable price, good service and a number of enterprises to establish a long-term partnership.
